Hydraulikvibratoren
Hydraulic
vibrators.
When the job is too rough for electric and compressed air is not available, the vehicle's own hydraulic circuit does the work. One type. Built for abuse.
Type MVO 850
85 kN
on demand.
The amplitude is set by the oil flow you give it. Open the valve, get more force. Close it, get none. No secondary controller, no frequency drive, no firmware.
- Type
- MVO 850
- Drive
- Hydraulic, vehicle on-board
- Oil flow
- 20 to 80 L/min
- Operating pressure
- Up to 210 bar
- Centrifugal force
- Steplessly adjustable, up to 85 kN
- Frequency
- Variable via flow
- Housing
- Cast steel, ribbed
- Mounting
- Flange, 4-bolt
- Connection
- SAE hydraulic couplings
- Ambient
- -20 °C to +80 °C
Dimensional drawing and oil flow curves will be wired on the paid build.
Where it mounts
Bolted to whatever
can take it.
Case
Dump trucks
Mounted to the tipper wall to release sticky loads of clay, sand or frozen aggregate without residue.
Case
Concrete mixers
Bolted to the drum support to shake out the last kilos of mix and extend drum service life.
Case
Mobile plant
Integrated on tractors, earthmovers and screen boxes where electricity is not available but hydraulic power is.
